Applications:
Vertical, single-stage submersible motor pump made of wear-resistant industrial materials in close-coupled design, for wet or dry installation, stationary and transportable version.
Handling of all types of abrasive or aggressive waste water in water and waste water engineering as well as industry, especially untreated sewage containing long fibres and solid substances, fluids containing gas / air, as well as raw, activated and digested sludge; sea water desalination.
Slection table
Vertical, single-stage submersible motor pump made of wear-resistant industrial materials in close-coupled design, for wet or dry installation, stationary and transportable version.
Handling of all types of abrasive or aggressive waste water in water and waste water engineering as well as industry, especially untreated sewage containing long fibres and solid substances, fluids containing gas / air, as well as raw, activated and digested sludge; sea water desalination.
Slection table
| impeller angle | Flow(Q) | Head(m) | Speed(r/min) | Power(kw) | Efficency(%) | Diameter for impeller(mm) | ||
| m3/h | l/s | shaft | motor | |||||
| -4° | 630 756 868 | 175 210 241 | 13.8 11.7 8.61 | 1450 | 30.58 29.54 25.69 | 34 | 80.95 84.89 82.28 | 283.5 |
| -2° | 752 864 983 | 209 240 273 | 14.0 11.8 8.79 | 35.88 34.01 29.85 | 40 | 82.93 85.30 81.95 | ||
| 0° | 799 925 1094 | 222 257 304 | 14.9 13.0 8.89 | 40.66 39.94 34.32 | 45 | 82.62 85.30 81.36 | ||
| +2° | 925 1030 1217 | 257 286 338 | 15.2 13.5 9.21 | 47.42 46.18 39.31 | 65 | 84.41 85.30 80.76 | ||
| +4° | 1026 1130 1328 | 285 314 369 | 15.5 13.8 9.44 | 53.35 51.79 43.26 | 65 | 84.27 85.30 82.16 | ||
